Linali oil immersion cooling asic miner system

Extremely quiet, extreme overclocking, extreme quietness

Price

$ 2050


Category: power supply

Cumulative views

1000

  • Oil cooler
    • 2 layer
    • 3 layer
    • 4 layer
Quantity
-
+

Stock

300

隐藏域元素占位

  • Description
    • Commodity name: Linali oil immersion cooling asic miner system
    • Commodity ID: LLYL01

    Extremely quiet, extreme overclocking, extreme quietness

    Tower Oil Cooled Server Cabinet(Support customization)



     Provide a better operating environment for the equipment, isolate external dust,

    greatly reduce the impact of oxidation, and real-time temperature control does

    not exceed 50 degrees Celsius, improve the service life of equipment,

    and enhance the efficiency of some equipment.





    The range of use

    Support various electronic devices such as servers: computers, storage servers, supercomputing servers, etc.



    WHAT IS OIL COOLING SYSTEM?

    Use special cooling oil, which has the effects of insulation, anti-oxidation high

    thermal conductivity,flame retardant and so on Cold and heat exchange is

     carried out through the heat exchanger, circulating convection the cold oil is
    discharged from the bottom, and after absorbing heat,

    it flows out from the top to achieve the effect of heat dissipation





    How the oil cooling system works?

    We can provide installation tutorials and one-to-onereal-time guidance,support bulk customization.

    The size of cooling water tower

    (for reference only)

    1KM power consumption ≈ 0.23 tons of heat exchange (1 ton = 1 m3)

    Main parameters of oil cooling system

    The bottom pulley block can bear 1200KG~1600KG, and the two fuel tank guide rails on one layer can bear 220KG

     Four-layer cabinet size:

    100*58*221CM, including bottom pulley, pulley height 11CM

                                                  weight: of 274KG accessories after installation (without oil) is about 368KG

    Four-layer electric box*4 sets: total weight 28KG4* (configuration:

    2 10A sockets (connected to oil pump network equipment);

    4 16A sockets (connected to the machine) do not participate in the warranty

    Three-layer cabinet size

    100*58*171CM, including bottom pulley, pulley height 11CM

    weight of 223KG accessories after installation (without oil) is about 291KG

    Three-layer electric box*3 sets:Total weight 21KG*3 (configuration:

    2 10A sockets (connected to oil pump network equipment);

    4 16A sockets (connected to the machine) do not participate in the warranty

     Two-layer cabinet size

    100*58*121CM, including bottom pulley, pulley height 11CM

    The weight of 174KG accessories after installation (without oil) is about 220KG

    Two-layer electric box * 2 sets:Total weight 14KG*2

    (configured with 2 10A sockets (connected to oil pump network equipment);

    4 16A sockets (connected to the machine) do not participate in the warranty.

    The current oil temperature can be displayed. After the current oil temperature reaches the set temperature,

                    The AC contactor intervenes to cut off the circuit. When the current oil temperature drops below the set

    temperature,the AC contactor restores the circuit; the warranty is 6 months.
